5.7 Main Contactor Fail (MCF)
Validate the correct operation of the ITM and MCF protection by applying a voltage on the load side of
the contactor. The voltage must be >10% of the rated voltage of the ITM. Ensure that a CBR trip is
initiated by the IPM which can only be reset by performing a locked reset.
5.8 Voltage Measurement
Validate the voltage measurement function of the IPM by checking the measured voltages on the IPM
screen when the main contactor is closed.
5.9 RS485 Interface
The correct operation of the RS485 interface is determined by polling the IPM relay from a RS485
capable device.
5.10 RTM (if Installed)
Validate the correct operation of the RTM by making changes to Group 2 settings, moving the machine
to a different outlet and ensuring that the correct settings are available on the new outlet.
5.11 Lock, Reset, Aux, Ex-Stop, Ex-Start & MCI Inputs
Ensure that the digital inputs to the IPM are operating correctly by operating each of the inputs and
ensuring that the IPM functions as expected.
