High Current Alarm
OFF, 100%, 108%, 120%, 140%, 160%, 200%, 240%, 280%, 320%,
360%, 400%, 500%, 600%
Current Balance
Trip Setting
OFF, 5%, 10%, 20%, 50%
Trip Time
2sec
Other Protection Functions
Under Voltage Protection
Trip Settings
40%, 50%, 60%, 70%, 75%, 80%, 85%, 90%, 95%, OFF
Trip Time
800ms
Fan (Burp) Function
Number of Pulses
None and 1 to 6 (selection of none disables the Burp Function)
Time On/Off
0.6, 0.8, 1.0, 1.2, 1.5, 2.0, 2.5 and 3.0sec
Pump (Snore) Function
None, 5,10,15, 20, 8F,15F,20F, 30F, 60F
Time in Minutes F= Fixed delay
16 EQUIPMENT LIST
Part Number
Description
143794
IPM Integrated Protection Relay 24V
121504
ITM-415 Insulation Test Module
121505
ITM-1000V Insulation Test Module
143315
RTM Remote Termination Module
101703
88mm Earth leakage Toroid
141548
Current Transformer 100:1 [500:5] 45mm I.D.
101272
Current Transformer 1000:1 45mm I.D.
101108
40mm M5 Screw
171010
Support Bracket
