15 SPECIFICATIONS
General
Auxiliary Supply Voltage
24 VDC ± 20%, <10W
Contact Ratings
MCR (1 N/O, 1 C/O), CBR and ALM (1 C/O) 5A/190VAC 100VA max
Communications
RS485 Slave Modbus
Baud Rate: 1200 to 19200
Monitoring
4-20mA Analogue Output
Back EMF Timer
Delay Settings
2, 5, 10, 15, 20 sec
Machine Numbers
Can be allocated from 1 to 40
Protection Functions
Earth Leakage
Trip Settings
OFF, 25, 50, 100, 200, 500mA
Trip Delay
Inst. (<80ms), 50ms, 100ms, 150ms
Alarm Setting
OFF, 10%, 20%, 30%, 40%, 50%, 60%, 80%
Earth Continuity
Shunt Trip
< 1850Ω
Operating Time
80, 120, 160, 200, 300, 400, 500ms
Trip Resistance
> 45Ω
Reset Resistance
< 45Ω
Earth Fault Lockout
Resistance
NONE, 1, 2, 5, 10, 20MΩ (test time 2 sec)
Alarm Setting
Trip setting x 1.5
Current Related Functions
Over Current Protection
Current Range
0.5125 to 64 Amps (224 steps) 100:1 CT
5.125 to 640 Amps (224 steps) 1000:1 CT
Trip Time (at 6xFLC)
3, 4, 5, 6, 7, 8, 10, 12, 14, 16, 20, 24, 28, 32, 40sec
Cooling Multiplier
1, 1.5, 2, 2.5, 3, 4, 5 times
Overload Reset Level
30%, 40%, 50%, 60%, 70%, 80%, 90%, A-30%, A-40%, A-50%, A-
60%, A-70%, A-80%, A-90%
Alarm Setting
OFF, 50%, 60%, 70%, 75%, 80%, 85%, 90%, 95%
Short Circuit Protection
Trip Settings
3.0 to 10.0 times in 0.5 increments (x FLC)
Trip Time
20, 40, 60, 80, 100, 120, 160ms
Under Current
Trip Setting
OFF, 32%, 40%, 48%, 56%, 64%, 72%, 80%, 88%, 96%
Alarm Setting
OFF, 32%, 40%, 48%, 56%, 64%, 72%, 80%, 88%, 96%
Residual Current
Trip Setting
OFF, 10%, 20%, 30%, 40%, 50%, 60%, 80%, 100%, 120%, 150%,
200%, 250%
Trip Time
OFF, 100ms, 200ms, 500ms, 1sec, 2, 3, 5sec
