Table 10: User Adjustable Settings
Group 2 Setting
Description
RTM Mach. Type
Selects the RTM descriptive code transmitted to
identify the machine connected to the outlet
RTM Mach. Num
Selects the assigned machine number to be
transmitted by the Remote Termination Module
100% Current
Sets the full load current
OC I mul
Combines with OC range to define the full load
current
Short Cct. Trp
Sets the short circuit trip level
Short Cct. t
Sets the trip time for the short circuit function
O/L trp t @6x
Modifies the basic overcurrent time curves to
achieve the desired trip times
O/L cool mult
Allows the cooling rate of the thermal model to be
modified
O/L Rst. Level
Sets the pre-set level to allow a reset of an O/L
trip
Cur. Bal. trp
Adjusts current phase balance trip
Under I level
Sets the under current threshold
Residual i Trp
Selects the residual current trip threshold as a %
of FLC
Res. Trip time
Sets the trip time for the residual current function
RCD Trp. Level
Sets the sensitivity trip level for the earth leakage
protection
RCD Trp. Time
Sets the trip time for the earth leakage protection
Pilot Trip t
Sets the trip time for the earth continuity
protection
Remote Start
When “Yes” is selected the IPM Relay ignores the
local start input. When “No” is selected the local
start/stop inputs control the relay
EC Trip Latch
Determines whether earth continuity trips are self-
resetting or not
Ins. Tst. Level
Sets the trip threshold or disables the insulation
test function
U/V Trp. Level
Sets the under voltage threshold
Back emf time
Adjustable time delay to inhibit main contactor
failure following opening of main contactor
High I alarm
Selects the high current alarm threshold as a %
of FLC
O/L Alarm Lev
Selects the overload alarm threshold as a % of
the thermal accumulator
Under I Alarm
Selects the under current alarm threshold as a %
of FLC
E/L Alarm Lev
Selects the alarm trip level for the earth leakage
protection
# Burp Pulses
Sets the number of burp pulses
Burp on Time
Sets the burp pulse on time
Burp Off Time
Sets the burp pulse off time
4-20mA Output
Sets the value to be transmitted
Snore Delay
Sets the Snore Delay Value
