The IPM status display is one of the most useful features of the relay‟s display system and should be
viewed as the first step in fault finding. The „Relay Status Page‟ is the default screen on power up and
shows the current status of the IPM Protection Relay.
[ Need IPM Start ]
Load [Pump # 1 ]
I= 0 Amps V= 0 V
Line 1: A one-line status message is displayed and if more than one message is active the
display cycles through all active messages at 1 second intervals.
Line 2: IPM Software version appears here while the UP arrow key held.
Line 3: Shows the Load Type and Number (from the connected RTM unit).
Line 4: Shows the Load Current (3ϕ average) and Load Voltage (average ϕ - ϕ.)
Through the use of the Modbus communications port, PLC‟s and SCADA systems can be configured to
display the same messages that appear on the display. This helps to provide consistent information to
operators.
12.2 Trip/Status Messages
The following table shows a list of the forty (40) status messages and the category (type) of the
messages. Messages are cleared according to their message category.
Type 1: Messages are latched for display and are cleared by either pressing the <ENT> key while
on the Status Display Page or by starting a new starting sequence.
Type 2: Messages are enabled and cleared automatically.
Type 3: Messages are triggered by the respective trip functions and are cleared by resetting the
trip function.
Table 3: Trip/Status Message
Voltage on load side of contactor is too low
MCI input did not close within 5 sec of MCR relay
closing
IPM detected (via MCI input) that MC was opened –
not initiated by the IPM relay
MCI input fails to follow MCR relay output during burp
phase
Under Current function tripped
IPM has exited the OTS Test Mode
