APPENDIX 4: IPM Menu Structure
Level
Menu
Level -
Screen
Menu Message /
Function
Sub Menu Display
Default
1
Need IPM
Start
1.1
Start / Status /
See Trip / Status Messages;
Error Messages
Type 1 – Latched for Display
Type 2 – Enabled & Cleared Automatically
Type 3 – Triggered by Trip Function
1.2-
1.50
Event Log : (last
50 events)
L2: Event, L3:
Time - Event,
L4 :Present Time
Pwr Up, Pwr Down, MCR Close, Stopped, Ext. Stop, MC Fail, Close Fail,
ECW Trip, EC Leak Trip, EL trip, Burp Done, Burp Fail, SC Trip, OC Trip,I
bal-Trp, RESET, Set up Mod,
2
Earth
Leakage
2.1
Current / Voltage
/ Overload
2.2
All Currents; E/L,
E/L, IB
% Trip Level to 100% Trip, Current Balance
3
Earth
Continuity
3.1
Earth Continuity
When either EC Res or Earth Loop Leakage reaches 100% a trip occurs
3.2
Insulation Test
Level
1MW, 2MW, 5MW, 10MW, 20MW (Alarm - 1.5 x Set Value)
Display shows last measured value
3.3
Status Indicator
Remote Input
4
IPM Relays &
Keys
4.1
IPM Relay &
Keys
CBR, MCR, ALM, MCI, Str, Rst, Stp
4.2
IPM Dig Inputs
ExtRst, ExtStp, ExtStr, Lock, Aux, A/O 4.0mA
4.3
Modbus Status
[Address, Read, Wrt, Exc, CRC, Par, NE, FE]
4.4
Clock Setup
[Day, Mth, Yr, Hrs, Mins & Sec] (Time Stamp – Events Log)
5
Settings:
Grp1-IPM
5.1
EC Pilot Mode
[Diode, RTM] –Earth Loop Resist. < 45W
5.2
ITM Module
[415v / 1000v]
5.3
Start Mode
[Selects Inputs Reqd. For Start Mode]
5.4
Modbus Addr
[1 -31]
5.5
Modbus : Baud
/P
[12000,E,N, 24000,E,N, 48000,E,N, 96000,E,N, 192000,E,N]
96000
5.6
Modbus T-out
0.5, 1.0, 2.0, 5.0, None
0.5 Sec
5.7
CT Ratio
100:1 and 1000:1
6
Settings:
Grp2-RTM
6.1
RTM Machine
Type
[J-bo, Fan, Dril, Pump, Hpmp, Wpmp, DCB,
Bolt, HRMr, Belt, Winc, Crsh, Dplg, Spare]
6.2
RTM Mach.
Num.
[ 1 to 40 ]
6.3
100% Current
[5.125A – 625A]
5.125A
6.4
Short Cct.Trp
[Selectable; 3.0 to 10 Times FLC]
3.0 x
6.5
Short Cct.t
[20, 40, 60,80,100, 120, 160 mSec]
20
