Level
Menu
Level -
Screen
Menu Message /
Function
Sub Menu Display
Default
mSec
6.6
O/L trp t @ 6x
3, 4, 5, 6, 7, 8, 10, 12, 14, 16, 20, 24, 28, 32, 40 Sec
3 Sec
6.7
O/L cool mult
[1.0 to 5.0] (ie 2.5 – Fan Cooled Mtr)
1.0
6.8
O/L Rst Level
[30% - 90%, A30% - A 90%] “A- Auto Reset
30%
6.9
Cur.Bal Trip
[5%, 10%, 20%, 50%, off]
5%
6.10
Under I Level
[32%, 40%,48%, 56%,64%, 72%, 80%, 88%, 96%, None ]
32%
6.11
Residual i Trip
[10, 20, 30, 40, 50, 60, 80, 100, 120, 150, 200, 250%]
10%
6.12
Res. trip time
[100mS, 1, 2, 3, 5 Sec]
100 mS
6.13
RCD Trp. Level
[25, 50 , 100, 200, 500mA]
25 mA
6.14
RCD Trp. Time
[50, 100, 150mSec]
50mSec
6.15
Pilot Trip t
[80, 120, 160, 200, 300, 400, 500mSec] (120mSec)
80mSec
6.16
Remote Start
No, Yes,
No
6.17
EC Trip Latch
[On / Off] For Reset – Operate Reset Button
On
6.18
Ins.Tst Level
1, 2, 5, 10, 20MW, None
1.0MW
6.19
U/V Trip level
[40, 50, 60, 70, 75, 80, 85, 90, 95%, Off]
40%
6.20
back emf time
[2 , 5, 10, 15, 20 Sec]
2 Sec
6.21
High I alarm
(Delay – 1s)
[100 – 600% FLC & Off]
100%
6.22
O/L Alarm Lev
(Delay – 2s)
50%, 60%, 70%, 75%, 80%, 85%, 90%, 95%, Alarm Off
50%
6.23
Under I Alarm
(Delay – 2s)
32%, 40%, 48%, 56%, 64%, 72%,80%, 88%, 96%, Off
32%
6.24
E/L Alarm Lev
(Delay – 1s)
10%, 20%, 30%, 40%, 50%,60%, 80%, Off
10%
6.25
Burp Pulses
[None, 1 to 6]
None
6.26
Burp On Time
[0.6, 0.8, 1.0, 1.2, 1.5, 2.0. 2.5. 3.0Sec]
0.6 Sec
6.27
Burp Off Time
[0.6, 0.8, 1.0, 1.2, 1.5, 2.0. 2.5. 3.0Sec]
0.6 Sec
6.28
4-20 Ma Output
[O/L : 0 – 100%, lave: 0-250%, E/L: 0 -100%, MW 0- 40MW
O/L
6.29
Snore Delay
Off, 5, 10, 15, 20, 8F, 15F, 20F, 30F, 60F (F= Fixed Delay)
Off
Type 1
EC Leak T
Type 2
Type 3
Tripped No Volts
EC Ω Trip
Outlet Paused
Snore-Close Aux
Earth Leakage Trip
RTM –Off Line Trip
MC Close Fail
MC
Opened
Need IPM Start
High Current Alarm
Earth Cont. Trip
IPM Memory Error
External MC Open
RTM Off L
Testing Insulation
Thermal Trip Alarm
Insulat. Fail Trip
RTM Memory Error
Burp MCI Fail
Und.I.Trp
Closing Main Cont.
Cur. Balance Alarm
Over Current Trip
Stopped – IPM
Under Current Trip
Stopped
Burp: MCR - Closed
Under Cur. Alarm
Short Circuit Trip
Last Trip Message
Ext.Stop
Burp: MCR - Open
Earth Leakage Alarm
I Balance Trip
Running
UnderVoltage Alarm
Residual Cur. Trip
Snore
Insulat.Test Alarm
Main Contactor Fail
