8.3 Voltage Metering
The Insulation Test Module (ITM) is also used to provide line voltage metering.
I&V A B C 2
Cur: 0% 0% 0%
Volts 0% 0% 0%
O/L: 0% MCF-t 100%
 L2: Displays the line current for each of the 3 phases.
 L3: Displays the line voltages for each of the 3 phases.
 L4: Displays the thermal accumulator and main contactor fail timer that counts down when a main
contactor fault is detected.
Line voltages of 415V and 1000V are configured when the appropriate Insulation Test Module is
selected in the „Group 1 Settings‟ (Level 5, Screen 2).
