6.0 SERVICE PROGRAMMING
6.1 SERVICE MODE
Access the service mode by pressing the yellow
mode button on the control board (Refer to Figure
3.1). If there are no errors, ACCOUNTING DATA is
displayed. Press # or * to scroll through the errors and
functions. Return to vend mode by closing the door,
pressing the mode switch or allowing the 2 minute
time-out to occur.
For convenience, there is an instruction card inside
the cabinet, and the back cover of this manual that
presents the basic information in this section in a flow-
chart format.
6.2 ERROR CODES
Any errors that have been recorded will be displayed
when the mode switch is pressed. Section 7.3
provides descriptions of errors and tips for
troubleshooting them.
ALWAYS CORRECT THE ERROR
BEFORE CLEARING THE MESSAGE!
1. # NEXT ERROR – View the next top level error
code.
2. 1. SUBLVL ERRORS – Displays any sublevel
error codes.
3. 2. DETAILS – Displays date and time of the last
sublevel error.
4. 0. CLEAR ERROR – Erases the error code from
memory.
6.3 ACCOUNTING DATA
Limited sales information can be displayed directly on
the vendor display. More detailed sales information is
contained in the DEX data. This data can be collected
with any DEX data collection system.
1. HIST. VENDS – Displays number of vends since
initialization of the control board.
2. HIST. CASH – Displays the total sales since
initialization of the control board.
3. RESET. VENDS – Displays the number of vends
since the last reset.
4. RESET. CASH – Displays the total sales since
the last reset.
5. HIST. SELECTIONS – Displays sequential
number of paid vends for each individual
selection since initialization of the control board.
Depending on the configuration, up to 80
selections may be audited.
Enter a selection by entering its characters. The
display will show the total paid count for the
selection for 2 seconds. At this time another
selection may be entered. All selections can be
accessed this way. Press # to exit to the
Accounting Menu.
6. CLEAR VALUES – Clears RESET. VENDS,
RESET. CASH, RESET CARD, and CASHBOX
COINS.
7. RESET. CARD – Displays the total cashless
sales since the last reset
8. CASHBOX COINS – Displays number and value
of coins delivered to the cashbox since last reset.
First the TOTAL Value of these coins is shown,
then by pressing * you can step through each
coin denomination
9. STACKED BILLS – Displays number and value
of bills stacked in the billbox since last reset.
First the TOTAL Value of these bills is shown,
then by pressing * you can step through each
coin denomination.
6.4 FILL/DISPENSE
The FILL/DISPENSE function allows the user to add
coins to the changer payout tubes or dispense coins
from the changer.
1. SELECT TUBE 1-6 - To dispense coins, press 1
through 6 (for a 6-tube changer) to dispense from
tubes 1-6. Tubes are numbered starting with the
lowest denomination. Each key press displays
the value of the coin being dispensed and the
total number of coins remaining in that tube.
2. OR INSERT COINS - To fill the changer, simply
drop coins in the coin slot. The display will show
the value of the coin and the total number of
coins in that tube. Note that coins can also be
added through the back of the changer. However,
the control will not be have an accurate count of
the coins in the tube unless the tube is filled
completely. When the high-level sensor in the
tube detects coins, the control will set the correct
coin count for that tube.
