7.3 ERROR CODES - CAUSES AND SOLUTIONS
ERROR CODES – CAUSES AND SOLUTIONS
TOP LEVEL
ERROR CODE
SUB LEVEL
CODE
CAUSES SOLUTIONS
OUT OF SERVICE
HS1
NONE
The internal temperature rose
above 41°F for 15 minutes.
The power was disconnected, the door was
not closed completely, or the refrigeration
system needs service/cleaning.
Check/clean screens. Check operation of
door switch. Check DATA LOGS in service
mode for more information.
OUT OF SERVICE
HS2
NONE
The internal temperature did
not cool to 41°F within 30
minutes after closing the door.
The door was open too long, warm product
was loaded, the door was not closed
completely, power was out, or the
refrigeration system needs
service/cleaning. Check/clean screens.
Check DATA LOGS in service mode for
more information
OUT OF SERVICE
HS3
NONE
The door switch was open
more than 30 minutes.
The door was not closed properly. If proper
operation is not restored by closing the
door, replace the door switch. Check for ‘-‘
when pressing * key.
X STUCK
NONE
Keypad selection button X
has been depressed more
than 2 minutes.
Clear any obstructions or dirt from around
the selection buttons and make sure they
can move freely. If proper operation is not
restored, replace the keypad.
PROD-SENSOR
NONE
The product sensor is blocked
or disconnected.
Remove any products or other objects in
the bottom, or in sensor openings in ends
of the delivery bin. Check sensor harness
connections.
SENSIT BLOCKED
NONE
The vend sensor is blocked or
lens is fogged.
Remove any obstructions from the path of
the sensor.
SENSIT
DISCONNECTED
NONE
The vend sensor is
disconnected.
Check all sensor harness connections.
HOME ERROR
NONE Motor switch problem.
Check for correct motor type. Check for
proper connections. Check for correct
motor set-up (See section 6.8)
MOTOR JAMMED
Displays
selection #
Excessive current draw. Caution! See section 7.4 below
CLEAN SCREEN
NONE
Reminder generated by
control board.
Not an error, but an aid for the service
person. See section 8.5.
7.4 CLEARING JAMMED MOTOR
If one or more motors and helices become jammed,
the motor(s) will be displayed as a sublevel error
under “Motor Jammed”.
Energized vend motors can turn a helix with
considerable torque, creating a possible
entrapment hazard. Disconnect power to the
vendor or control board before freeing a jammed
helix or motor. Always restrain or block the helix
before freeing a jammed or caught product.
CAUTION: Use caution when freeing jammed
product (Refer to Section 2.2)!
Clear any jammed products from the indicated vend
columns.
To reset the error, first enter service mode, then
select Tray Setup (Refer to Section 6.8). Press “1”,
then “ * “, then “3”. The control will attempt to run the
jammed motors. If the motor had been taken out of
the motor matrix, it will be re-established in the matrix.
