Settings Pages
36
Modero S Series Touch Panels - Configuration & Programming Manual
2. Enter the STUN server address and click OK.
3. Click Save to save your changes to the SIP page and return to the Configuration page.
Advanced Conf ig
The Advanced Config page (FIG. 59) displays options for more advanced configuration options, such as running diagnostics or
modifying the options for streaming video.
Cache Settings
The options on the Cache Settings page (FIG. 60) allow setting and clearing of the flash memory cache, as well as viewing the
status of the current cache settings. The G4 graphics engine caches images to decrease load time of previously viewed images.
RAM caching is always enabled, and both static and dynamic images are stored in the RAM cache as they are viewed.
FIG. 58 SIP STUN Address Keyboard
FIG. 59 Advanced Config page
Advanced Conf ig Page
Back: Click the left-facing arrow to return to the previous page.
Connection Status: A green bar signifies that the panel has an active connection to the Master.
Close: Click the “X” button to shut the Settings page and return to the main display.
Image Cache Settings
and Status:
Select this to open the Cache Settings page (page 36)
Diagnostics: Select this to open the Diagnostics page (page 37).
Streaming Video: Select this to open the Streaming Video page (page 39).
FIG. 60 Cache Settings page
