Modero S Series ® Programming
9
Modero S Series Touch Panels - Configuration & Programming Manual
Modero S Series
®
Programming
Overview
This document focuses on programming information for the Modero S Series touch panels. For more information on designing
touch panel pages intended to optimize the Modero S Series experience, please refer to the TPDesign4 Operation Reference Guide
and the User Interface Design Guide, both available at www.amx.com. The Modero S-Series touch panels covered in this document
are listed in the following table:
Modero S-Series Touch Panels
MST-1001 FG2265-05 10.1" Modero S Series Tabletop Touch Panel
MSD-1001 FG2265-01 10.1" Modero S Series Wall Mount Touch Panel
MST-701 FG2265-06 7" Modero S Series Tabletop Touch Panel
MSD-701 FG2265-02 7" Modero S Series Wall Mount Touch Panel
MST-431 FG2265-07 4.3" Modero S Series Tabletop Touch Panel
MSD-431 FG2265-03 4.3" Modero S Series Wall Mount Touch Panel

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
