Programming
62
Modero S Series Touch Panels - Configuration & Programming Manual
Button Commands (Cont.)
^GIV Invert the joystick axis to move the origin to another corner. Parameters 1,2, and 3 will cause a bargraph or slider to be
inverted regardless of orientation. Their effect will be as described for joysticks.
•Syntax:
"'^GIV-<vt addr range>,<joystick axis to invert>'"
•Variables:
variable text address range = 1 - 4000.
joystick axis to invert = 0 - 3.
For a bargraph 1 = Invert, 0 = Non Invert
•Example:
SEND_COMMAND Panel,"'^GIV-500,3'"
Inverts the joystick axis origin to the bottom right corner.
^GLH Change the bargraph upper limit.
•Syntax:
"'^GLH-<vt addr range>,<bargraph hi>'"
•Variables:
variable text address range = 1 - 4000.
bargraph limit range = 1 - 65535 (bargraph upper limit range).
•Example:
SEND_COMMAND Panel,"'^GLH-500,1000'"
Changes the bargraph upper limit to 1000.
^GLL Change the bargraph lower limit.
•Syntax:
"'^GLL-<vt addr range>,<bargraph low>'"
•Variables:
variable text address range = 1 - 4000.
bargraph limit range = 1 - 65535 (bargraph lower limit range).
•Example:
SEND_COMMAND Panel,"'^GLL-500,150'"
Changes the bargraph lower limit to 150.
^GRD Change the bargraph ramp-down time in 1/10th of a second.
•Syntax:
"'^GRD-<vt addr range>,<bargraph ramp down time>'"
•Variables:
variable text address range = 1 - 4000.
bargraph ramp down time = In 1/10th of a second intervals.
•Example:
SEND_COMMAND Panel,"'^GRD-500,200'"
Changes the bargraph ramp down time to 20 seconds.
^GRU Change the bargraph ramp-up time in 1/10th of a second.
•Syntax:
"'^GRU-<vt addr range>,<bargraph ramp up time>'"
•Variables:
variable text address range = 1 - 4000.
bargraph ramp up time = In 1/10th of a second intervals.
•Example:
SEND_COMMAND Panel,"'^GRU-500,100'"
Changes the bargraph ramp up time to 10 seconds.
^GSC Change the bargraph slider color or joystick cursor color. A user can also assign the color by Name and R,G,B value
(RRGGBB or RRGGBBAA).
•Syntax:
"'^GSC-<vt addr range>,<color value>'"
•Variables:
variable text address range = 1 - 4000.
color value = Refer to the RGB Triplets and Names For Basic 88 Colors table on page 90.
•Example:
SEND_COMMAND Panel,"'^GSC-500,12'"
Changes the bargraph or joystick slider color to Yellow.
0
2
3
1
1 = Invert hor izonta l axi s
2 = Invert vertical axis
3 = Invert both axis locations
0 = Nor mal

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
