AMX MST-1001 Configuration Manual

Programming
80
Modero S Series Touch Panels - Configuration & Programming Manual
Audio Commands
SIP Commands - Master to Panel (Cont.)
^PHN-SETUP-PORT Setup port for SIP Server connection command - Sets the port number for the proxy server.
•Syntax:
"'^PHN-SETUP-PORT,<port>'"
•Variable:
port: The port for the proxy server
•Example:
SEND_COMMAND Panel,"'^PHN-SETUP-PORT,5060'"
Set this extension to connect to the SIP server (SIP proxy address) to port 5060.
^PHN-SETUP-PROXYADDR Setup SIP server address command - Sets the IP address for the SIP server (SIP proxy address).
•Syntax:
"'^PHN-SETUP-PROXYADDR,<IP>'"
•Variable:
IP: The IP address for the proxy server
•Example:
SEND_COMMAND Panel,"'^PHN-SETUP-PROXYADDR,192.168.223.111'"
Set the extension to try the SIP server (SIP proxy address) at the IP of 192.168.223.111.
^PHN-SETUP-STUNADDR Sets the IP address for the STUN server.
Syntax:
"’^PHN-SETUP-STUNADDR,<IP>’"
Variable:
IP = The IP address for the STUN server
Example:
SEND_COMMAND Panel,"’^PHN-SETUP-STUNADDR,192.168.223.111’"
^PHN-SETUP-USERNAME Setup SIP username command - Sets the user name for authentication with the SIP server (SIP proxy
address).
•Syntax:
"'^PHN-SETUP-USERNAME,<username>'"
•Variable:
username: The user name (usually the phone extension)
•Example:
SEND_COMMAND Panel,"'^PHN-SETUP-USERNAME,6003'"
Set the extension to authenticate to the SIP server with the username of 6003.
Audio Commands
^ADS Selects the audio device to use.
Syntax:
"'^ADS-<device>'"
Variables:
1 = Built-in Speaker
2 = USB Headset
3 = Bluetooth Headset
?ADS Queries the currently selected audio device (returned in custom event).
Syntax:
"'?ADS'"
Queries the currently selected audio device (returned in custom event).
CUSTOM.TYPE = EVENTID = 1325
CUSTOM.ID = ADDRESS = 0
CUSTOM.FLAG = 0
CUSTOM.VALUE1 = Device type (1=Built-in speaker, 2=USB Headset, 3=Bluetooth Headset)
CUSTOM.VALUE2 = 0
CUSTOM.VALUE3 = 0
CUSTOM.TEXT = blank
^ICM Sets the microphone level during an intercom call. Used to set the microphone level during an intercom call (0 to 100).
Syntax:
"'^ICM-MICLEVEL,<level>,[device]'"
Set the state of the microphone on a panel to muted (1) or unmuted (0). At the start of each call the microphone starts out
unmuted.
"'^ICM-SPEAKERLEVEL, <level>,[device]'"
Intercom modify command.
Used to set the speaker level during an intercom call (0 to 100).

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
