Modero S Series Touch Panels - Configuration & Programming Manual
Master to Panel
The following table lists and describes SIP commands that are sent to the touch panel to manage calls.
SIP Commands - Panel to Master
^PHN-PRIVACY SIP call privacy status - Indicates the state of the privacy feature.
•Syntax:
"'^PHN-PRIVACY,<state>'"
•Variables:
state = 0 (Disable) or 1 (Enable)
new message count = The number of new messages.
old message count = The number of old messages.
new urgent message count = The number of new messages marked urgent.
old urgent message count = The number of old messages marked urgent.
•Example:
^PHN-PRIVACY,0
The panel sent a command status to the master indicating there the call privacy is disabled.
^PHN-REDIAL SIP call redial status - Indicates the panel is redialing the number.
•Syntax:
"'^PHN-REDIAL,<number>'"
•Variable:
number = The phone number to dial.
•Example:
^PHN-REDIAL,2125551000
The panel sent a command status to the master indicating the number 2125551000 is being redialed.
^PHN-TRANSFERRED SIP call transferred status - Indicates a call has been transferred.
•Syntax:
"'^PHN-TRANSFERRED,<connection id>'"
•Variable:
connection id: The identifying number of the connection.
•Example:
^PHN-TRANSFERRED,1
The panel sent a command status to the master indicating call 1 was transferred.
SIP Commands - Master to Panel
^PHN-ANSWER SIP call answer command - Answers the call.
•Syntax:
"'^PHN-ANSWER,<connection id>'"
•Variable:
connection id = The identifying number of the connection
•Example:
SEND_COMMAND Panel,"'^PHN-ANSWER,1'"
Answer call 1.
^PHN-AUTOANSWER SIP set auto-answer state command - Enables (1) or disables (0) the auto-answer feature on the phone.
•Syntax:
"'^PHN-AUTOANSWER,<state>'"
•Variable:
state = 0 (Disable) or 1 (Enable)
•Example:
SEND_COMMAND Panel,"'^PHN-AUTOANSWER,1'"
Enable the auto-answer feature.
?PHN-AUTOANSWER Get SIP auto-answer state command - Queries the state of the auto-answer feature.
The panel responds with the ^PHN-AUTOANSWER, <state> message.
•Syntax:
"'?PHN-AUTOANSWER'"
•Example:
SEND_COMMAND Panel,"'?PHN-AUTOANSWER'"
Get the auto-answer status.

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
