AMX MST-1001 Configuration Manual

Programming
42
Modero S Series Touch Panels - Configuration & Programming Manual
Panel Commands (Cont.)
@AKP Pop up the keypad icon and initialize the text string to that specified. Keypad string is set to null on power up and is stored
until power is lost. The Prompt Text is optional.
•Syntax:
"'@AKP-<initial text>;<prompt text>'"
•Variables:
initial text = 1 - 50 ASCII characters.
prompt text = 1 - 50 ASCII characters.
•Example:
SEND COMMAND Panel,"'@AKP-12345678;ENTER PASSWORD'"
Pops up the Keypad and initializes the text string '12345678' with prompt text ’ENTER PASSWORD’.
@AKR Remove keyboard or keypad that was displayed using 'AKEYB', 'AKEYP', 'PKEYP', @AKB, @AKP, @PKP, @EKP, or @TKP
commands.
•Syntax:
"'@AKR'"
•Example:
SEND COMMAND Panel,"'@AKR'"
Removes the Keyboard/Keypad.
BEEP Output a beep.
•Syntax:
"'BEEP'"
•Example:
SEND COMMAND Panel,"'BEEP'"
Outputs a beep.
BRIT Set the panel brightness.
•Syntax:
"'BRIT-<brightness level>'"
•Variables:
brightness level = 0 - 100.
•Example:
SEND COMMAND Panel,"'BRIT-50'"
Sets the brightness level to 50.
@BRT Set the panel brightness.
•Syntax:
"'@BRT-<brightness level>'"
•Variables:
brightness level = 0 - 100.
•Example:
SEND COMMAND Panel,"'@BRT-70'"
Sets the brightness level to 70.
DBEEP Output a double beep.
•Syntax:
"'DBEEP'"
•Example:
SEND COMMAND Panel,"'DBEEP'"
Outputs a double beep.
@EKP Extend the Keypad.Pops up the keypad icon and initializes the text string to that specified. The Prompt Text is optional.
•Syntax:
"'@EKP-<initial text>;<prompt text>'"
•Variables:
initial text = 1 - 50 ASCII characters.
prompt text = 1 - 50 ASCII characters.
•Example:
SEND COMMAND Panel,"'@EKP-33333333;Enter Password'"
Pops up the Keypad and initializes the text string '33333333' with prompt text 'Enter Password'.

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
