Modero S Series Touch Panels - Configuration & Programming Manual
Programming Numbers
The following information provides the programming numbers for colors, fonts, and borders.
Colors can be used to set the colors on buttons, sliders, and pages. The lowest color number represents the lightest color-specific
display; the highest number represents the darkest display. For example, 0 represents light red, and 5 is dark red.
RGB Triplets and Names For Basic 88 Colors
RGB Values for all 88 Basic Colors
Index No. Name Red Green Blue Index No. Name Red Green Blue
00 Very Light Red 255 0 0 45 Medium Aqua 0 80 159
01 Light Red 223 0 0 46 Dark Aqua 0 64 127
02 Red 191 0 0 47 Very Dark Aqua 0 48 95
03 Medium Red 159 0 0 48 Very Light Blue 0 0 255
04 Dark Red 127 0 0 49 Light Blue 0 0 223
05 Very Dark Red 95 0 0 50 Blue 0 0 191
06 Very Light Orange 255 128 0 51 Medium Blue 0 0 159
07 Light Orange 223 112 0 52 Dark Blue 0 0 127
08 Orange 191 96 0 53 Very Dark Blue 0 0 95
09 Medium Orange 159 80 0 54 Very Light Purple 128 0 255
10 Dark Orange 127 64 0 55 Light Purple 112 0 223
11 Very Dark Orange 95 48 0 56 Purple 96 0 191
12 Very Light Yellow 255 255 0 57 Medium Purple 80 0 159
13 Light Yellow 223 223 0 58 Dark Purple 64 0 127
14 Yellow 191 191 0 59 Very Dark Purple 48 0 95
15 Medium Yellow 159 159 0 60 Very Light Magenta 255 0 255
16 Dark Yellow 127 127 0 61 Light Magenta 223 0 223
17 Very Dark Yellow 95 95 0 62 Magenta 191 0 191
18 Very Light Lime 128 255 0 63 Medium Magenta 159 0 159
19 Light Lime 112 223 0 64 Dark Magenta 127 0 127
20 Lime 96 191 0 65 Very Dark Magenta 95 0 95
21 Medium Lime 80 159 0 66 Very Light Pink 255 0 128
22 Dark Lime 64 127 0 67 Light Pink 223 0 112
23 Very Dark Lime 48 95 0 68 Pink 191 0 96
24 Very Light Green 0 255 0 69 Medium Pink 159 0 80
25 Light Green 0 223 0 70 Dark Pink 127 0 64
26 Green 0 191 0 71 Very Dark Pink 95 0 48
27 Medium Green 0 159 0 72 White 255 255 255
28 Dark Green 0 127 0 73 Grey1 238 238 238
29 Very Dark Green 0 95 0 74 Grey3 204 204 204
30 Very Light Mint 0 255 128 75 Grey5 170 170 170
31 Light Mint 0 223 112 76 Grey7 136 136 136
32 Mint 0 191 96 77 Grey9 102 102 102
33 Medium Mint 0 159 80 78 Grey4 187 187 187
34 Dark Mint 0 127 64 79 Grey6 153 153 153
35 Very Dark Mint 0 95 48 80 Grey8 119 119 119
36 Very Light Cyan 0 255 255 81 Grey10 85 85 85
37 Light Cyan 0 223 223 82 Grey12 51 51 51
38 Cyan 0 191 191 83 Grey13 34 34 34
39 Medium Cyan 0 159 159 84 Grey2 221 221 221
40 Dark Cyan 0 127 127 85 Grey11 68 68 68
41 Very Dark Cyan 0 95 95 86 Grey14 17 17 17
42 Very Light Aqua 0 128 255 87 Black 0 0 0
43 Light Aqua 0 112 223 255 TRANSPARENT 99 53 99
44 Aqua 0 96 191

AMX MST-1001 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Touchscreen type	Tabletop
Display brightness	350 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Touchscreen technology	Resistive
Viewable size diagonal	256 mm
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Product color	Black
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	136 x 217 mm
Power supply type	DC
Power consumption (standby)	4.5 W
Power consumption (typical)	7.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Wall mountable	No
HDMI ports quantity	0
Graphics card	AMX G4
Internal memory	512 MB
Internal memory type	DDR
RMS rated power	1.5 W

Weight and Dimensions

Depth (without stand)	103 mm
Width (without stand)	264 mm
Height (without stand)	157 mm
Weight (without stand)	5530 g
