Example System Points

B-4 Infinity Smoke Control Guide

TOC

FL2RADmp.OVR.Cls Numeric Floor2 Return Air Smoke Damper “CLOSE” Override

Switch on FSCS

FL2RADmp.OVR.Opn Numeric Floor2 Return Air Smoke Damper “OPEN” Override

Switch on FSCS

FL2RADmp.ST.Fail Numeric Floor2 Return Air Smoke Damper Self-Test Fail Flag

FL2SADmp.Cls Numeric Floor2 Supply Air Smoke Damper “CLOSED” LED on

FSCS

FL2SADmp.Fail Numeric Floor2 Supply Air Smoke Damper “FAIL” LED on FSCS

FL2SADmp.Opn Numeric Floor2 Supply Air Smoke Damper “OPEN” LED on

FSCS

FL2SADmp.OVR.Cls Numeric Floor2 Supply Air Smoke Damper “CLOSE” Override

Switch on FSCS

FL2SADmp.OVR.Opn Numeric Floor2 Supply Air Smoke Damper “OPEN” Override

Switch on FSCS

FL2SADmp.ST.Fail Numeric Floor2 Supply Air Smoke Damper Self-Test Fail Flag

FL2VAV.Cls Numeric Floor2 VAV Damper “CLOSED” LED on FSCS

FL2VAV.Fail Numeric Floor2 VAV Damper “FAIL” LED on FSCS

FL2VAV.Opn Numeric Floor2 VAV Damper “OPEN” LED on FSCS

FL2VAV.OVR.Cls Numeric Floor2 VAV Damper “CLOSE” Override Switch on FSCS

FL2VAV.OVR.Opn Numeric Floor2 VAV Damper “OPEN” Override Switch on FSCS

FL3RADmp.Cls Numeric Floor3 Return Air Smoke Damper “CLOSED” LED on

FSCS

FL3RADmp.Fail Numeric Floor3 Return Air Smoke Damper “FAIL” LED on FSCS

FL3RADmp.Opn Numeric Floor3 Return Air Smoke Damper “OPEN” LED on

FSCS

FL3RADmp.OVR.Cls Numeric Floor3 Return Air Smoke Damper “CLOSE” Override

Switch on FSCS

FL3RADmp.OVR.Opn Numeric Floor3 Return Air Smoke Damper “OPEN” Override

Switch on FSCS

FL3RADmp.ST.Fail Numeric Floor3 Return Air Smoke Damper Self-Test Fail Flag

FL3SADmp.Cls Numeric Floor3 Supply Air Smoke Damper “CLOSED” LED on

FSCS

FL3SADmp.Fail Numeric Floor3 Supply Air Smoke Damper “FAIL” LED on FSCS

FL3SADmp.Opn Numeric Floor3 Supply Air Smoke Damper “OPEN” LED on

FSCS

FL3SADmp.OVR.Cls Numeric Floor3 Supply Air Smoke Damper “CLOSE” Override

Switch on FSCS

FL3SADmp.OVR.Opn Numeric Floor3 Supply Air Smoke Damper “OPEN” Override

Switch on FSCS

FL3SADmp.ST.Fail Numeric Floor3 Supply Air Smoke Damper Self-Test Fail Flag

FL3VAV.Cls Numeric Floor3 VAV Damper “CLOSED” LED on FSCS

Table B-1.

CX9200

Points

NAME TYPE DESCRIPTION
