Andover Controls Infinity User Manual

Example System Points
Andover Controls Corporation B-5
TOC
FL3VAV.Fail Numeric Floor3 VAV Damper “FAIL” LED on FSCS
FL3VAV.Opn Numeric Floor3 VAV Damper “OPEN” LED on FSCS
FL3VAV.OVR.Cls Numeric Floor3 VAV Damper “CLOSE” Override Switch on FSCS
FL3VAV.OVR.Opn Numeric Floor3 VAV Damper “OPEN” Override Switch on FSCS
FL4RADmp.Cls Numeric Floor4 Return Air Smoke Damper “CLOSED” LED on
FSCS
FL4RADmp.Fail Numeric Floor4 Return Air Smoke Damper “FAIL” LED on FSCS
FL4RADmp.Opn Numeric Floor4 Return Air Smoke Damper “OPEN” LED on
FSCS
FL4RADmp.OVR.Cls Numeric Floor4 Return Air Smoke Damper “CLOSE” Override
Switch on FSCS
FL4RADmp.OVR.Opn Numeric Floor4 Return Air Smoke Damper “OPEN” Override
Switch on FSCS
FL4RADmp.ST.Fail Numeric Floor4 Return Air Smoke Damper Self-Test Fail Flag
FL4SADmp.Cls Numeric Floor4 Supply Air Smoke Damper “CLOSED” LED on
FSCS
FL4SADmp.Fail Numeric Floor4 Supply Air Smoke Damper “FAIL” LED on FSCS
FL4SADmp.Opn Numeric Floor4 Supply Air Smoke Damper “OPEN” LED on
FSCS
FL4SADmp.OVR.Cls Numeric Floor4 Supply Air Smoke Damper “CLOSE” Override
Switch on FSCS
FL4SADmp.OVR.Opn Numeric Floor4 Supply Air Smoke Damper “OPEN” Override
Switch on FSCS
FL4SADmp.ST.Fail Numeric Floor4 Supply Air Smoke Damper Self-Test Fail Flag
FL4VAV.Cls Numeric Floor4 VAV Damper “CLOSED” LED on FSCS
FL4VAV.Fail Numeric Floor4 VAV Damper “FAIL” LED on FSCS
FL4VAV.Opn Numeric Floor4 VAV Damper “OPEN” LED on FSCS
FL4VAV.OVR.Cls Numeric Floor4 VAV Damper “CLOSE” Override Switch on FSCS
FL4VAV.OVR.Opn Numeric Floor4 VAV Damper “OPEN” Override Switch on FSCS
FLR2TCX.Fail Numeric Floor2 TCX Controller “FAULT” LED on FSCS
FLR2TCX.OVRR Numeric Floor2 TCX Controller “OVERRIDE” LED on FSCS
FLR3TCX.Fail Numeric Floor3 TCX Controller “FAULT” LED on FSCS
FLR3TCX.OVRR Numeric Floor3 TCX Controller “OVERRIDE” LED on FSCS
FLR4TCX.Fail Numeric Floor4 TCX Controller “FAULT” LED on FSCS
FLR4TCX.OVRR Numeric Floor4 TCX Controller “OVERRIDE” LED on FSCS
FSCSLinkActive Numeric Flag that tells the “Main” Program that the
“FSCS_Interface” Program is Active
Horn Numeric Audible Annunciator Output on FSCS
LampTest Numeric “LAMP TEST” Pushbutton Input on FSCS
Main.Key Numeric “MASTER KEY” Keyswitch Input on FSCS
Table B-1.
CX9200
Points
NAME TYPE DESCRIPTION
