Andover Controls Infinity User Manual

Example System Points
B-6 Infinity Smoke Control Guide
TOC
MaxCtlrTime Numeric Maximum Time that a Controller can be OFFLINE
Before a Fault is Generated
MaxDamperTime Numeric Maximum Time for a Damper to Reach it’s Desired
Position
MaxFanTime Numeric Maximum Time for a Fan to Reach it’s Desired State
SelfTested Numeric Flag that is Turned ON After the System has Completed
it’s Weekly Self-Test
SMKDMPRS.Fail Numeric Smoke Damper Controller “FAULT” LED on FSCS
SMKDMPRS.OVRR Numeric Smoke Damper Controller “OVERRIDE” LED on FSCS
SMOKE.ALM Numeric Flag that is Turned ON when ANY of the Zones are in
Alarm
SpareLamp Numeric Spare Outputs on FSCS
SpareSwitch Numeric Spare Inputs on FSCS
STRWL.ALM Numeric Stairwell “ALARM” LED on FSCS
STRWL.CON Numeric Stairwell
Zoned Wiring Alarm Input on FSCS
STRWL.EST Numeric Stairwell Xdriver Alarm Input from the Fire Panel
STRWL.PRS Numeric Stairwell “PRESSURIZE” Override Switch on FSCS
STRWL.SMK Numeric Stairwell Smoke Control Sequence is Active
Zone1.ALM Numeric Zone1 “ALARM” LED on FSCS
Zone1.CON Numeric Zone1
Zoned Wiring Alarm Input on FSCS
Zone1.EST Numeric Zone1 Xdriver Alarm Input from the Fire Panel
Zone1.EXH Numeric Zone1 “EXHAUST” Override Switch on FSCS
Zone1.PRS Numeric Zone1 “PRESSURIZE” Override Switch on FSCS
Zone1.SMK Numeric Zone1 Smoke Control Sequence is Active
Zone2.ALM Numeric Zone2 “ALARM” LED on FSCS
Zone2.CON Numeric Zone2
Zoned Wiring Alarm Input on FSCS
Zone2.EST Numeric Zone2 Xdriver Alarm Input from the Fire Panel
Zone2.EXH Numeric Zone2 “EXHAUST” Override Switch on FSCS
Zone2.PRS Numeric Zone2 “PRESSURIZE” Override Switch on FSCS
Zone2.SMK Numeric Zone2 Smoke Control Sequence is Active
Zone3.ALM Numeric Zone3 “ALARM” LED on FSCS
Zone3.CON Numeric Zone3
Zoned Wiring Alarm Input on FSCS
Zone3.EST Numeric Zone3 Xdriver Alarm Input from the Fire Panel
Zone3.EXH Numeric Zone3 “EXHAUST” Override Switch on FSCS
Zone3.PRS Numeric Zone3 “PRESSURIZE” Override Switch on FSCS
Zone3.SMK Numeric Zone3 Smoke Control Sequence is Active
Zone4.ALM Numeric Zone4 “ALARM” LED on FSCS
Zone4.CON Numeric Zone4
Zoned Wiring Alarm Input on FSCS
Zone4.EST Numeric Zone4 Xdriver Alarm Input from the Fire Panel
Table B-1.
CX9200
Points
NAME TYPE DESCRIPTION
