Andover Controls Infinity User Manual

Example System Points
B-8 Infinity Smoke Control Guide
TOC
Table B-2. SCX920S
SMKDMPRS
Points
NAME TYPE DESCRIPTION
Fl2.SASDmp.Opn Input 1
Digital
Floor2 Supply Air Smoke Damper OPEN Proof
Sensor
Fl2.SASDmp.Cls Input 2
Digital
Floor2 Supply Air Smoke Damper CLOSED
Proof Sensor
Fl2.RASDmp.Opn Input 3
Digital
Floor2 Return Air Smoke Damper OPEN Proof
Sensor
Fl2.RASDmp.Cls Input 4
Digital
Floor2 Return Air Smoke Damper CLOSED
Proof Sensor
Fl3.SASDmp.Opn Input 5
Digital
Floor3 Supply Air Smoke Damper OPEN Proof
Sensor
Fl3.SASDmp.Cls Input 6
Digital
Floor3 Supply Air Smoke Damper CLOSED
Proof Sensor
Fl3.RASDmp.Opn Input 7
Digital
Floor3 Return Air Smoke Damper OPEN Proof
Sensor
Fl3.RASDmp.Cls Input 8
Digital
Floor3 Return Air Smoke Damper CLOSED
Proof Sensor
Fl4.SASDmp.Opn Input 9
Digital
Floor4 Supply Air Smoke Damper OPEN Proof
Sensor
Fl4.SASDmp.Cls Input 10
Digital
Floor4 Supply Air Smoke Damper CLOSED
Proof Sensor
Fl4.RASDmp.Opn Input 11
Digital
Floor4 Return Air Smoke Damper OPEN Proof
Sensor
Fl4.RASDmp.Cls Input 12
Digital
Floor4 Return Air Smoke Damper CLOSED
Proof Sensor
Fl2.SASDmp Output 1
Digital
Floor2 Supply Air Smoke Damper Control
Fl2.RASDmp Output 2
Digital
Floor2 Return Air Smoke Damper Control
Fl3.SASDmp Output 3
Digital
Floor3 Supply Air Smoke Damper Control
Fl3.RASDmp Output 4
Digital
Floor3 Return Air Smoke Damper Control
Fl4.SASDmp Output 5
Digital
Floor4 Supply Air Smoke Damper Control
Fl4.RASDmp Output 6
Digital
Floor4 Return Air Smoke Damper Control
DefaultDmprPosn Numeric Damper Position when NOT Performing Smoke
Control
OverrideOn Numeric Flag that Indicates that an Output is Overridden
at the Controller
