3-51
3.3 Mechanical configuration
3.3.5 Front unit disassembly/assembly
Remove TFT LCD MODULE
2
(1) After 3.3.3 (2) 1) and 2) procedures, remove the S3 screws and remove
2
,
3
,
4
to pull forward.
(2) After removing the S4 screws and each cables, remove the LCD
2
.
To assemble, perform inversely
Parts List
1
322B13832 Front panel
2
No1256 TFT LCD MODULE
3
332B40222 LCD panel
4
322B13833 Front cover
5
33E32858 Encoder knob
6
34Y118357 A02 FRONT BOARD
7
34Y115415 MOTHER BOARD
To Next Page
