2.3.3 Front unit disassembly/assembly
Removing TFT LCD MODULE
(1) After removing the S1, S2 screws and encoder knob
5
, remove the front panel
1
.
(2) After removing the S3 screw, remove the
2
,
3
and
to pull forward.
(3) After removing the S4 screw and each cables, remove the LCD
2
.
To assemble, perform inversely.
Parts List
1
322B13049 Front panel
2
No1256 TFT LCD MODULE
3
332B40222 LCD panel
4
322B13048 Front cover
5
33E32858 Encoder knob
6
34Y106676 A02 FRONT BOARD
7
34Y106673 A01 MOTHER BOARD
2.3 Mechanical configuration
