Anritsu MS2665C - 3.3 Mechanical Configuration

3-33
3.2 Troubleshooting
3.3 Mechanical configuration
3.3.1 Disassembling/Assembling cabinet
(1) Removing Feet (
1
to
8
)
Remove the S1 screws and remove the S2/S3 screws of the rear.
(2) Removing around cover (
10
)
Remove the four S1 screws (
1
to
4
) and remove the S3 screw of the rear.
Remove the around cover (
10
) to pull backward.
(3) Removing Front Frame (
11
)
After (1) removing procedure, remove the
11
to pull forward.
To assemble, perform inversely.
Parts List
1
32E11805A Front foot
2
32E11805B Front foot
3
32E11806A Front foot Receiver
4
32E11806B Front foot Receiver
5
32E11807A Rear foot
6
32E11807B Rear foot
7
32E11808A Rear foot Receiver
8
32E11808B Rear foot Receiver
9
34Y107601 Tilt handle
10
323B14135 Around cover assembly
11
32E13058 Front frame
