3.3 Mechanical configuration
3.3.3 Disassembling/Assembling Components around RF Input
Removing Diplexing Bandswitch
1
, Switched Attenuator
, AK-AKF PANEL Connector
7
.
(1) Removing Diplexing Bandswitch
1
After 3.3.1 (2) removing procedure, remove the S1 screws and Disconnect Diplexing Bandswitch’s connector which
is connected to Swithched Attenuator
2
.
(2) Removing Switched Attenuator
2
1) After (1) procedure, remove the S2/S3/S4/S5/S6 screws and remove encorder knob
3
and the front panel
4
to
pull forward.
2) Remove the S7/S8/S9 screws and remove the angle
5
, which Swiched Attenuator
2
and Block
6
, are Attached
to pull backward.
3) Remove the S10 screws and disconnect AK-AKF PANEL CONNECTOR’s (
7
) connector which is connected to
Swithched Attenuator
2
.
(3) Removing AK-AKF PANEL CONNECTOR
7
After (2) procedure, remove the W1 washer and N1 nut and remove AK-AKF PANEL CONNECTOR
7
by rotating
it.
To assemble, perform inversely.
Parts List
1
D29870 Diplexing Bandswitch
2
D29638 Switched Attenuator
3
33E32858 Encoder knob
4
322B13832 Front panel
5
33B40005 Angle
6
34H115321 BLOCK
7
B46790 AK-AKF PANEL CONNECTOR
