Anritsu MS2665C - Removing;Assembling Units and PC Boards

2-35
2.3.2 Removing/Assembling units and PC boards
(1) Removing MICRO CONVERTER
4
and 1ST LO AMP
5
After removing the screws and each cables, remove the
4 5
to pull backward.
(2) Removing Step Attenuator
3
Band ATT Angle
2
After removing the S1/S2 screws, remove the
2 3
.
(3) Removing 21 GHz YTF/SW
7
After removing the Angle
8
, remove the
7
(4) Removing PMC/GPIB
18
and CPU board
17
After removing the S3 screw, remove the
17 18
to pull backward.
To assemble, perform inversely.
Parts List
1
34J107713 N-J SMA-P Adapter
2
332B36744B ATT Angle
3
339H37752 21GHz Step Attenuator
4
34Y110446C A13 MICRO CONVERTER
5
34Y110447 A14 1ST LO AMP
6
329H13290 H.MIXER
7
329H13289 21GHz YTF/SW
8
34B111361 Angle
9
33B38019 Plate
10
34J110924 Semi-rigid cable
11
439H32078 SMA-Attenuator
12
34J117955 Semi-rigid cable
13
33J41281 Semi-rigid cable
14
33J41282 Semi-rigid cable
15
34J110713 Semi-rigid cable
16
34J117700 Semi-rigid cable
17
34Y106690 A03 CPU
18
34Y106693 A04 PMC/GPIB
or 34Y106692B or A04 PMC/CENTRONICS
2.3 Mechanical configuration
