2-43
2.3.4
A09 OPTION BASE disassembly/assembly
Parts List
1
34Y106684
A09 OPTION BASE
2
34Y106695
A0901 TRIG/GATE
3
34Y106699
A0902 AM/FM MONITOR
4
34Y106697
A0903 TV MONITOR
5
34Y113473
A0904 QP DETECTOR
or 34Y117105
2.3
Mechanical configuration
