3.3 Mechanical configuration
3.3.2 Removing/Assembling units and PC boards
Removing RF CONVERTER
7
, PC Boards (
3
to
6
), Power Supply
2
.
(1) After 3.3.1 (2) removing procedure, remove the S1/S2/S3/S4/S5 screws and remove the rear panel
1
.
(2) Removing PC Boards (
3
to
6
)
After (1) removing procedure, remove PC Boards (
3
to
6
) to pull backward.
(3) Removing RF CONVERTER
7
After (1) removing procedure, remove the S6/S7/S8 screws and remove the unit
7
to pull backward.
(4) Removing Power Supply
2
After (1) removing procedure, remove the S9 screws and remove the Power Supply
2
to pull backward.
To assemble, perform inversely.
Parts List
1
323B14028 Rear panel
2
34Z114508 Power supply
3
34Y111112B LOCAL-SP2
34Y111111B LOCAL-SP1
4
34Y106718B IF (B)
5
34Y106684B OPTION BASE
6
34Y112923D SCAN/AD
7
34Y117226 RF CONVERTER
