Anritsu VNA master User Manual

E-1 Coaxial Cable Technical Data Coaxial Cable Technical Data
E-4 PN: 10580-00305 Rev. J MS20xxC UG
Times LMR100 0.66 1000 0.789 2000 1.15 2500 1.31
Times LMR200 0.83 1000 0.342 2000 0.49 2500 0.554
Times LMR240 0.84 1000 0.261 2000 0.377 2500 0.424
Times LMR400 0.85 1000 0.135 2000 0.196 2500 0.222
Times LMR500 0.86 1000 0.109 2000 0.159 2500 0.18
Times LMR600 0.87 1000 0.087 2000 0.128 2500 0.145
Times LMR900 0.87 1000 0.059 2000 0.086 2500 0.098
Times LMR1200 0.88 1000 0.044 2000 0.065 2500 0.074
Times LMR1700 0.89 1000 0.033 2000 0.049 2500 0.057
310801 0.821 1000 0.115 1000 0.115 1000 0.115
311201 0.82 1000 0.18 1000 0.18 1000 0.18
311501 0.8 1000 0.23 1000 0.23 1000 0.23
311601 0.8 1000 0.262 1000 0.262 1000 0.262
311901 0.8 1000 0.377 1000 0.377 1000 0.377
352001 0.8 1000 0.377 1000 0.377 1000 0.377
Table E-1. Coaxial Cable Technical Data (Sheet 4 of 4)
Manufacturer Cable
Prop.
Vel.
Freq
1
Loss
1
Freq
2
Loss
2
Freq
3
Loss
3
