6-6 Time Domain Options Menu (VNA Mode) System Operations
6-8 PN: 10580-00305 Rev. J MS20xxC UG
6-6 Time Domain Options Menu (VNA Mode)
This menu is available only when Option 2, the Time Domain Option, is installed. More
information is available in the Vector Network Analyzer Measurement Guide (listed in
Appendix A).
Key Sequence: Shift, System (8)>Application Options > Time Domain
VNA mode selected
Reflection Calc in Time
One Way Round Trip: Press this soft key (submenu key) to toggle the
setting for the calculation method that is used in the time domain (not
distance) reflection measurements. The method can be either One Way
(divide the total time by 2) or Round Trip.
Gate Coupled
On Off: Press this soft key (submenu key) to toggle the gate coupling On or
Off. When set to On, the gate settings (start, stop, and so forth) for all traces
are the same. When set to Off, each trace has a gate whose settings are
independent of any of the other gates that are being used.
Domain Processing
Auto BP Only: Press this soft key to toggle domain processing to Auto or
to BP Only. In Auto, the instrument selects Low Pass processing whenever
possible and switches to Band Pass if not possible. In BP Only, the setting will
never be Low Pass.
Back: Press this soft key to return to the “Application Options Menu (VNA
Mode)” on page 6-7.
Figure 6-8. Application Options Menu (VNA Mode)
Back
Time Domain Options
Reflection Calc in Time
One Way Round Trip
Gate Coupled
On Off
Domain Processing
Auto BP Only
