2-17 File Types Quick Start Guide
2-34 PN: 10580-00305 Rev. J MS20xxC UG
2-17 File Types
Filename extensions that are used in the VNA Master:
*.jpg JPEG images, filename.jpg
*.mna Measurements, filename.mna
*.stp Setups, filename.stp
*.s2p S2P (SnP), filename.s2p
*.spa Spectrum Analyzer measurements, filename.spa
*.csv Text file with Comma Separated Values (CSV), filename.csv
*.txt Text file with tab separated values, filename.txt
*.lim Limit lines, filename.lim (Limit lines are available only in Spectrum Analyzer
mode.)
File Management
A description of the file menu group is in the VNA Menus chapter of the VNA Measurement
Guide (refer to Appendix A). That section includes instructions for saving, recalling, copying,
and deleting files.
Note
S2P is a standard ASCII text file format that is used for scattering parameters from
a 2-Port measurement. This is a subset of SnP (where n equals the number of
ports). An S2P file can be used as input for signal analysis.
The CSV and Text files contain setup information and final formatted data that are
shown on the instrument display screen. This file information includes any
post-processing that was done on the data (smoothing, trace math, time domain,
and so forth). These files contain the data for any traces that are displayed,
including the memory traces. They also contain the markers that are turned on
when the file is saved.
