General Information 1-8 Soft Carrying Case and Tilt Bail
MS20xxC UG PN: 10580-00305 Rev. J 1-5
1-8 Soft Carrying Case and Tilt Bail
The soft carrying cases for the MS202xC and the MS203xC accommodate the different
instrument sizes. The part numbers are in the Technical Data Sheet. The tilt bail is
factory-installed on the VNA Master for use with or without the soft carrying case.
VNA Master Soft Carrying Case
The MS20xxC can be operated while in the soft carrying case. On the back of the case is a
large storage pouch for accessories and supplies.
To install the MS20xxC into the soft carrying case, perform the following:
1. The front panel of the case is secured with hook and loop fasteners. Fully open the front
panel of the case.
2. Place the soft carrying case face down on a stable surface, with the front panel fully
open and laying flat.
3. Fully open the zippered back of the case.
4. Insert the MS20xxC face down into the case, taking care that the connectors are
properly situated in the case top opening. Figure 1-3 shows the MS20xxC in the case.
Note
Two zippers are located around the back of the case. The zipper closer to the
MS20xxC compartment of the case opens the case back and allows access to install
and remove the MS20xxC. The other zipper closer to the back of the case opens a
support panel that can be used to provide support for improved stability and air flow
while in the case. This support panel also contains the storage pouch.
Figure 1-3. Instrument Inserted Into the Soft Carrying Case
