GPS Receiver, Option 31 7-3 GPS Menu
MS20xxC UG PN: 10580-00305 Rev. J 7-3
7-3 GPS Menu
GPS
On Off: Press this soft key to toggle the GPS feature On and Off.
GPS Info: Press this soft key to open a window with additional GPS
information. Press the Esc key to close the window.
GPS Voltage
3.3V 5V: Press this soft key to toggle the voltage to 3.3 volts or 5 volts.
This voltage is supplied by the instrument to the GPS antenna.
Reset: Press this soft key to set the number of tracked satellites to 0 and to
erase any almanac data, along with saved coordinates. The process of
searching for and reacquiring satellites will begin again.
Back: Press this soft key to return to the.previous menu
Figure 7-4. GPS Menu
Back
GPS Info
Reset
GPS
On Off
GPS Voltage
3.3 V 5 V
GPS
