System Operations 6-5 Application Options Menu (VNA Mode)
MS20xxC UG PN: 10580-00305 Rev. J 6-7
6-5 Application Options Menu (VNA Mode)
This menu is specific to the VNA application.
Key Sequence: Shift, System (8)>Application Options
Standard VNA menus selected.
Units
mft:Press this soft key (submenu key) to toggle the units setting to metric
(meters, or m) or to U.S. (feet, or ft). Press Enter to accept the changes, or
press the Esc key to return to normal operation without changing the setting.
External Reference: Press this soft key to toggle between the two choices of
turning Off the external reference or selecting the external reference.
Trace Label
On Off: Press this soft key (submenu key) to toggle the trace labels On or
Off.
Meas Gain Range: Press this soft key to open the “Meas Gain Range Menu
(VNA Mode)” on page 6-9. Then select Auto or Fixed.
Time Domain
On Off: Press this submenu key to open the “Time Domain Options Menu
(VNA Mode)” on page 6-8.
Back: Press this soft key to return to the “System Menu” on page 6-4.
Figure 6-7. Application Options Menu (VNA Mode)
Back
Options
Units
m ft
Trace Label
On Off
Meas Gain Range
Auto
External Reference
Off 10 MHz
Time Domain
