Quick Start Guide 2-14 Symbols and Indicators
MS20xxC UG PN: 10580-00305 Rev. J 2-31
When the battery is not present, the battery symbol is replaced by a red plug body
(Figure 2-20) to indicate that the instrument is running from external power. When the
external AC adaptor is connected, the battery automatically receives a charge, and the
battery symbol with the lightning bolt is displayed (Figure 2-19). When the battery is fully
charged, the charging circuit shuts off and the green battery symbol (100% charged) is
displayed without the lighting bolt (Figure 2-18)..
Hold
A Hold message is displayed when the VNA Master is on hold. To resume sweeping, toggle
from Hold to Run in the Sweep menu.
Single Sweep
The Single Sweep symbol is displayed when Single Sweep is selected. Single or Continuous
sweep can be selected under the Sweep Menu.
Figure 2-20. Battery Not Charging or Not Available
