Anritsu VNA master - Page 136

F-4 Flange Compatibility Waveguide Data
F-4 PN: 10580-00305 Rev. J MS20xxC UG
Universal Flange Compatibility
Table F-4. Universal Flange Compatibility (2 of 3)
Calibration
Component
Part Number
Start
Frequency
(GHz)
Stop
Frequency
(GHz)
Waveguide
Type
Flange
Type
Compatible
Flanges
xxUA187 3.950 5.850 WR187
WG12
UnivUS-187 CPR187F
CPR187G
UG-1352/U
UG-1353/U
UG-1728/U
UG-1729/U
UG-148/U
UG-149A/U
xxUA159 4.900 7.050 WR159
WG13
UnivUS-159 CPR159F
CPR159G
UG-1354/U
UG-1355/U
UG-1730/U
UG-1731/U
xxUA137 5.850 8.200 WR137
WG14
UnivUS-137 CPR137F
CPR137G
UG-1356/U
UG-1357/U
UG-1732/U
UG-1733/U
UG-343B/U
UG-344/U
UG-440B/U
UG-441/U
xxUA112 7.050 10.00 WR112 WG15 UnivUS-112 CPR112F
CPR112G
UG-1358/U
UG-1359/U
UG-1734/U
UG-1735/U
UG-52B/U
UG-51/U
UG-137B/U
UG-138/U
