Anybus CompactCom M40 User Manual

Appendix E: Anybus CompactCom 40 without Housing 106 (114)
Fastening Screw
Recommended screw tightening torque is 0.3 Nm (tolerance ±10 %).
2.8
+
3
°
+5°
140°
20
°
Detail “X”
Penetration depth: 1.00/1.30
EJOT DELTA PT Schraube WN 5451 30x10
EJOT TORX PLUS/AUTOSERT 10IP
0.8
1.12
±0.10
0
- 0.12
+0.45
±0.08
2.09
- 0.45
+0.10
max. 1.5
03
10
+0.12
2.3
6.5
-0.56
max. R0.5
“X”
Fig. 63
Anybus
®
CompactCom
™
M40 Hardware Design Guide HMSI-216-126 EN 2.6
