Rev.
Description
Date
Sign
Weight
Finishing
Owner
HMS nr
1
Sign:
1
1:1
Stationsgatan 37
S-302 45 Halmstad
Tel: +46 (0)35 - 17 29 00
Fax: +46 (0)35 - 17 29 09
Title
Date:
Rev.
of
Sheet:
Document nr
Size
Scale
HMS Industrial Networks AB
The information contained in this drawing is the sole property of HMS Industrial Networks AB. Any reproduction in part or whole whitout the written permission of HMS Industrial Networks AB is prohibited
SP1137
20120313
RiA
1.6
Compact Flash connector HMS
SDH-7018-202
38,7
40,2
2,3
3,6
3
8,1
50,87
3,5
0,45
0,635
1,7
2,4
18,5
0,9
46
11,5
15
31,115
Recommended PCB-layout
General tolerances ±0,05mm
DETAIL D
Enable usage of
other connectors
(Second Source)
Position hole
Position knob
D
Pin 1
Pin 25
Pin 50
1. Housing: LCP(Liquid Crystal Polymer
)
Color:Natural,Thermoplastic,UL 94 V-0
2. Contact:
Copper Alloy
3. Operation voltage: 100 VAC max
4. Current rating: 0.5 Amp.
5. Contact resistance: 40m ohms max.
6. lnsulation resistance: 1000M ohms min 500 VDC.
7. Dielectric withstanding voltage: 500VAC/1minute.
8. Operating Temperature: -40 C to +85 C
9. Resistance o Solder Heat :
Temperature: 260
Immersion duration: 10sec.
10.Durability: 5000 Cycles
11.Finish/Plated:
T
ermi an l:15u" Au Plated on Contact Area,
100u" in Tin Plated on solder area,
50u" in Ni Under Plated o ver all
C
o
o
o
12.RoHS and REACH compliant
13.Storage -25 - 65°C, 0 - 90% RH
t
in
m
m
m
Grounded Pin: 80u min Tin Plated on solder area,
50u min Ni Under Plated over all
"
"
1.4 Added support for pins and HMS logotype
RiA
2013-09-30
Enable usage of
other connectors
50,7
PCB outline
1.5 Added pcb-outline to pcb-layout
RiA
2014-05-05
+0,4 *
-0,0
* For PCB and drill-hole tolerances
1.6 Updated PCB outline value
RiA
2014-07-16
Fig. 45
