Apollo Thunderbolt User Manual

Apollo Thunderbolt Software Manual Device Drivers 204
Apollo Twin Default I/O (ADAT Mode)
Apollo Twin Default I/O Table
Digital Input Mode: ADAT
INPUTS OUTPUTS
1
MIC/LINE/Hi-Z 1
1 MON L
2
MIC/LINE 2
2 MON R
3 MON L* 3 LINE 3
4 MON R* 4 LINE 4
5 VIRTUAL 1* 5 VIRTUAL 1*
6 VIRTUAL 2* 6 VIRTUAL 2*
7 VIRTUAL 3* 7 VIRTUAL 3*
8 VIRTUAL 4* 8 VIRTUAL 4*
9 ADAT 1 9 HP L
10 ADAT 2 10 HP R
11 ADAT 3
12 ADAT 4
13 ADAT 5
14 ADAT 6
15 ADAT 7
16 ADAT 8
17 AUX1 L*
18 AUX1 R*
19 AUX2 L*
20 AUX2 R*
21 TALKBACK 1†
22 TALKBACK 2†
*Software Outputs
(for DAW inputs)
*Software Inputs
(for Console inputs)
†Apollo Twin MkII only
Apollo Twin ADAT Input Channels and Sample Rates
The ADAT digital input recognizes the following channels and sample rates:
• Channels 1 – 8 at 44.1 kHz and 48 kHz
• Channels 1 – 4 at 88.2 kHz and 96 kHz
• Channels 1 – 2 at 176.4 kHz and 192 kHz

Apollo Thunderbolt Specifications

General

Type	Audio Interface
Connectivity	Thunderbolt
Bit Depth	24-bit
DSP	UAD-2
Sample Rate	192 kHz
Thunderbolt Ports	2
DSP Processing	UAD-2
Software Included	UAD Software
