Current Bank Overview
An important navigational concept in Console is the Current Bank. The Current Bank is
all input channels that are currently displayed in the main body of the Console window
(below the Meter Bridge) as shown in the illustration on the next page.
The gray Bank Bar is used to change the Current Bank. For complete details, see Current
Bank.
Conceptual illustration of the Current Bank.
In this example, the Current Bank is analog channels 3 through 6.
Sliding the Bank Bar brings different channels into the Current Bank view.
Slide gray Bank Bar
to change Current Bank
Bank Bar
(gray)
Current Bank
(visible channels)
Channels not
within Bank Bar
Channels not
within Bank Bar
Meter
Bridge
