Apollo Thunderbolt Software Manual Device Drivers 206
Apollo, Apollo 8 Default I/O
Apollo, Apollo 8 Driver Default I/O Table
INPUTS OUTPUTS
1 MIC/LINE/Hi-Z 1 1 MON L
2 MIC/LINE/Hi-Z 2 2 MON R
3 MIC/LINE 3 3 LINE 1
4 MIC/LINE 4 4 LINE 2
5 LINE 5 5 LINE 3
6 LINE 6 6 LINE 4
7 LINE 7 7 LINE 5
8 LINE 8 8 LINE 6
9 ADAT 1 9 LINE 7
10 ADAT 2 10 LINE 8
11 ADAT 3 11 ADAT 1
12 ADAT 4 12 ADAT 2
13 ADAT 5 13 ADAT 3
14 ADAT 6 14 ADAT 4
15 ADAT 7 15 ADAT 5
16 ADAT 8 16 ADAT 6
17 S/PDIF L 17 ADAT 7
18 S/PDIF R 18 ADAT 8
19 VIRTUAL 1* 19 S/PDIF L
20 VIRTUAL 2* 20 S/PDIF R
21 VIRTUAL 3* 21 VIRTUAL 1*
22 VIRTUAL 4* 22 VIRTUAL 2*
23 VIRTUAL 5* 23 VIRTUAL 3*
24 VIRTUAL 6* 24 VIRTUAL 4*
25 VIRTUAL 7* 25 VIRTUAL 5*
26 VIRTUAL 8* 26 VIRTUAL 6*
27 MON L* † 27 VIRTUAL 7*
28 MON R* † 28 VIRTUAL 8*
29 AUX1 L* † 29 CUE1 L
30 AUX1 R* † 30 CUE1 R
31 AUX2 L* † 31 CUE2 L
32 AUX2 R* † 32 CUE2 R
33 CUE3 L (N/A)
34 CUE3 R (N/A)
35 CUE4 L (N/A)
36 CUE4 R (N/A)
* Software Outputs
(for DAW inputs)
*Software Inputs
(for Console inputs)
† In multi-unit setups, available on monitor unit only
