3.3.2. Serial Ports
There are two serial (COM) ports labeled respectively as COM1 and COM2.
COM1 is implemented as an RS232 level port without support for hardware handshaking.
COM2 is an RS232 level port with support for hardware handshaking through associated
CTS and RTS lines.
Pin #
Function
1
n/c
2
COM2 RS232 CTS
3
Event 1 input
4
Event 2 input
5
n/c
6
GND
7
COM1 RS232 Tx
8
COM1 RS232 Rx
9
USB DP
10
n/c
11
COM2 RS232 RTS
12
COM2 RS232 Tx
13
n/c
14
n/c
15
USB ID
16
Ethernet RD-
17
Ethernet TD-
18
USB DM
19
USB VBUS
20
PPS out
21
COM2 RS232 Rx
22
n/c
23
GND
24
Power
25
Ethernet RD+
26
Ethernet TD+
Figure 12: Power / IO Connector Pin-Out
