2. Accelerate the vehicle in a straight line as quickly as possible to a speed of at least 60
km/h.
• Once target speed is reached, apply vehicle brakes and come to full stop as quickly
as possible.
• Turn vehicle around and repeat until INS Heading Accuracy values drop
significantly.
Note: Ensure there is no GNSS multipath present. It is important that the vehicle
accelerations be performed in a straight line.
3. Change the maneuver to perform a number of turns (e.g. circular or figure 8) in an area
where there is a minimum of GNSS multipath.
• Monitor the calibration progress in the GNSS Lever Arms window to ensure the INS
Heading Accuracy is getting smaller and approaching the Target Heading
Accuracy.
• Once the INS Heading Accuracy meets, or exceeds, the Target Heading
Accuracy, go to the next section.
MARINE VESSELS
Once the set-up procedure is complete, proceed with the following calibration procedure
for marine vessels
1. Open the Receiver Configuration, INS page and GNSS Lever Arms tab.
• Click on the Calibrate button. This puts the system into a specific mode to calibrate
the baseline vector.
2. Maneuver to perform a number of turns (e.g. figure 8’s or s-turns) in an area where there
is a minimum of GNSS multipath.
• Monitor the calibration progress in the GNSS Lever Arms window to ensure the INS
Heading Accuracy is getting smaller and approaching the Target Heading
Accuracy.
• Once the INS Heading Accuracy meets, or exceeds, the Target Heading
Accuracy, go to the next section.
Please contact Applanix for specific instructions for calibrating GAMS on a UAV.
