Page 77
4.1.8
NH3 Sensor kit
NH3 sensor kit for use in laboratories, livestock, poultry farms and sewage treatment plants to monitor the
leakage of ammonia gas and give an alarm to protect humans and animals.
Kit consists of DOL53 sensor, wire junction box TDADCA01 and Aranet 0-10 VDC transmitter. Sensor and
transmitter are connected to junction box which is powered by 220-240 VAC. In addition, Aranet 0-10V
transmitter is powered by 1 AA size battery. Connection scheme if following:
