LS-200 User Manual
4www.arec.com
Specifications
Featuring a compact and stand-alone design, AREC LS-200 Media Station consists of diverse features and functionality,
including multi-signals capturing, recording synchronously, codec, streaming online, live broadcasting, and web-based
monitor page, providing complete presentation or lecture capture solution.
Product Name Media Station
Model Name LS-200
Dimension 354mm(L) x 188.2mm(W) x 46mm(H)
Weight 1710g
Power Requirement 12V/2A
Power Consumption (Max.) 24W (Max.)
Operating Temperature / Humidity 0ºC ~ 40ºC / 90%
Maximum normal load description
Insert 1 IP CAM to LAN port or insert 2 video signals (either HDMI or VGA input).
Using external USB flash to record the transcoded video/audio. And output the
transcoded video/audio to both HDMI and VGA port.
Introduction
Package Contents
AREC LS-200 Media Station
Quick Installation Guide Terminal Block
Wireless Mic. Antenna
Power Adapter
