Arec LS-200 - Playback Video

LS-200 User Manual
34www.arec.com
Limitation
1. Video length(Max.) : 8hr
2. If Front USB is FAT32, USB record size only 4 GB space time.
Rule
2. Loop recording off
c. Front USB recording on and internal hard drive > USB
• If USB < 8hr : max = USB, show the dialog
3. Loop recording on (internal hard drive = 8hr)
a. Front USB recording on and internal hard drive > USB
• If USB < 8hr : max = USB, show the dialog
1. Loop recording off
a. Front USB recording off : If internal hard drive < 8hr : max =
internal hard drive, show the dialog
b. Front USB recording on and internal hard drive < USB
• If internal hard drive < 8hr : max = internal hard drive, show
the dialog
2. video recording
2.1.2.3 Playback Video
a
b
c
f
d
e
Show all videos saved in hard drive,three videos in one page.
a.Date of video
b.Start-End time of video
c.Total time of video
d.File list page up
e.File list page down
f.Video list pages,click to jump to different video list page.
Video list Dialog
