ldx SIdx name type Attr.
mapped on
PDO
default notes
1 GOST 17216 unsigned 8 ro y offset of one to display
00 and 0
0 == GOST 00
1 == GOST 0
2 == GOST 1
…………
17 == GOST 16 (maxi-
mum value)
2020h commando unsigned 8 wo
1 = start of a
measurement
2 = stop of a
measurement
3 = result between
2030h measurement
related settings
record
0 number of entries unsigned 8 ro 4h largest sub index
1 measurement time unsigned 32 rw Measurement Time in s
2 hold time unsigned 32 rw Time between
Measurements
3 operation mode unsigned 16 rw 0 = time Control
1 = digital I/O
2 = button
3 = automatic
4 history disable unsigned 16 rw 0h 0 = history enabled
1 = history disabled
2031h startup settings record
0 number or entries unsigned 8 ro 4h largest sub index
1 start mode unsigned 16 rw 0h 0 = Network with NMT
Master (Init => PreOp =>
Start_Remote_Node =>
Operational)
>0 = Network without
NMT Master
(Init => Operational)
2 communication type unsigned 16 rw enabled communication
interface:
0: RS232
1: CANopen
2: auto
3: J1939
3 baud rate CAN unsigned 16 rw baudr ate CAN:
3: 125k 4: 250k 5: 500k
6: 1000k
4 baud rate RS232 unsigned 16 rw baud rate RS232:
0: 9600 1: 19200 2:
57600 3: 115200
2032h
standard & alarm
related settings
record
0 number of entries unsigned 8 ro 9h largest sub index
1 display & alarm
standard
unsigned 16 rw displayed Standard and
alarm trigger bit setting
0 = ISO
1 = SAE
2 = NAS
3 = GOST
2 alarm type unsigned 16 rw 0 = standard alarm
1 = filter mode
