24. Appendix
24.1 Cable lengths
The tables show the maximum cable lengths for different transmission rates.
Baud rate Max. cable length
9600 150 m
19200 15 m
57600 5 m
115200 <2 m
24.2 Coding of error bits
Every ERC is displayed in hexadecimal notation and consists of four characters (0-F). The conversion for each character is based on
the following tables.
hexadecimal binary
0 0000
1 0001
2 0010
3 0011
4 0100
5 0101
6 0110
7 0111
8 1000
9 1001
A 1010
B 1011
C 1100
D 1101
E 1110
F 1111
Table 45: Cable lengths RS 232
Table 46: Calculation hexadecimal to binary
