ldx SIdx name type Attr.
mapped on
PDO
default notes
3 alarm value
temperature
unsigned 8 rw range: 0..85 °C
0 = disabled
4 alarm value
ISO/SAE4µm
unsigned 8 rw alarm threshold 4µm
(note the offset)
5 alarm value
ISO/SAE6µm
unsigned 8 rw alarm threshold 4µm
(note the offset)
6 alarm value
ISO/SAE14µm
unsigned 8 rw alarm threshold 4µm
(note the offset)
7 alarm value
ISO/SAE21µm
unsigned 8 rw alarm threshold
4µm (note the offset)
8 alarm value NAS unsigned 8 rw alarm threshold NAS
(note the offset)
9 alarm value GOST unsigned 8 rw alarm threshold GOST
(note the offset)
2100h
readmem control
functions
record
0 number of entries unsigned 8 ro 4h largest sub index
1 size of history
memory
unsigned 32 ro device
dependent
size of memory in
datasets
2 used history mem unsigned 32 ro used datasets within
memory
(corresponds internally
to write pointer)
3 reading pointer,
dataset
unsigned 32 rw autoincrementing read
pointer to a dataset for
history memory reading;
can be between 0 and
current write pointer
4 clear history memory unsigned 16 wo 1 = clear memory
2101h 0
readmem Initiate
segmented SDO
data upload
unsigned 32 ro
Appropriate Pointer
has to be set
(with 2100sub3)
before start reading,
Size of the record will
be sent back on
reading
16.2 CAN J1939
For further information see www.argo-hytos.com
Function available only from software version 2.00.15.
Table 34: Communication-related object dictionary
