Argo Xplorer XR 700 EPS 2023 User Manual

81
General Maintenance
6. Measure the thickness of each brake
pad. If the thickness of the pads are
less than 0.039 in (1 mm), take your
ATV to an authorized ARGO dealer to
have the brake pads replaced.
7. Install the wheel and install wheel nuts.
8. Tighten in a crisscross pattern to
45 ft-lb (61 N-m).
9. Remove the support stand
and jack.
Front Brake
Brake Pad Wear Limit:
0.039 in (1 mm)
Rear Brakes
Brake Pad Wear Limit:
0.039 in (1 mm)
Front Brakes
